Product parameters

Product Name: Pressure Transmitter, Model: MBS 3000

Pressure range: 0 to 25 bar

0 to 362.6 psi

Output signal: 4-20 mA

Pressure connection: G 1/4 (conforming to EN 837 standard)

Electrical connection: Pg 9, DIN-plug

Supply voltage: 10-30 V DC

Accuracy: Typical accuracy: ±0.5% FS (full scale)

Maximum accuracy: ±1.0% FS

Operating temperature range: -40 to 85 °C (-40 to 185 °F)

Medium temperature range: -40 to 85 °C

Response time: < 4 ms

Protection grade: IP65 (Dust and water resistant)

Material: Acidic stainless steel (AISI 316L), fully welded design

Certification: ATEX Ex nA IIA T3 Gc (Applicable to Explosive Hazardous Environments)

Function

High-precision measurement: Provides a standard output signal of 4-20 mA to ensure accurate pressure monitoring.

Anti-vibration and durability: Excellent anti-vibration performance and a sturdy structure make it suitable for long-term use.

EMC/EMI protection: High-level electromagnetic compatibility and anti-interference capability ensure stable operation in complex electrical environments.

Compact design: Small in size, it is easy to install in applications with limited space.

Wide temperature adaptability: It can operate normally in extreme temperatures ranging from -40 °C to 85 °C.

ATEX certification: Applicable to explosive hazardous environments (such as gas environments), in compliance with ATEX Ex nA IIA T3 Gc standards.

Corrosion resistance: Made of acidic stainless steel, it is suitable for contact with corrosive media.

Application scenarios

Pump system: It is used to monitor and control the pressure of industrial pumps to ensure the efficient operation of the system, and is commonly found in water pumps and hydraulic pumps.

Compressor: Measure pressure in the air compressor system, optimize performance and protect equipment.

Pneumatic system: Used for pressure control in pneumatic equipment, providing stable operational data.

Water treatment: Monitor the pressure of pipelines or equipment in water treatment facilities to ensure process safety and efficiency.

General industrial environment: Suitable for manufacturing, energy, chemical and other industries, especially in scenarios that require high precision and durability.

Harsh environment: Due to its anti-vibration, high-temperature resistance and EMC/EMI protection features, it is suitable for use in industrial environments with intense vibration, large temperature fluctuations or severe electromagnetic interference.
