Product parameters
Pressure range: 0-1.6 bar (Absolute pressure, Absolute)
Output signal: 4-20mA (Standard analog output, suitable for industrial control systems)
Supply voltage: 9-32 V DC
Accuracy: ±0.5% FS (full scale, typical value), maximum ±1.0% FS
Pressure connection: NPT 1/4-18 (Standard pressure interface)
Electrical connection: DIN 43650-A, PG9 plug (Angle connector)
Protection grade: IP65, suitable for harsh environments
Medium temperature range: -40°C to +85°C
Ambient temperature range: -40°C to +85°C
Material: Acidic stainless steel (AISI 316L), fully welded design, corrosion-resistant
Shock and vibration resistance: Excellent shock and vibration resistance, meeting the requirements of Marine applications
Response time: Up to 4 ms (suitable for media with viscosity up to 100 cSt)
EMC/EMI protection: High electromagnetic compatibility, meeting strict Marine and industrial standards
Overload pressure: Maximum 6 bar
Ship certification: Certified by LR, DNV, GL, RINA, ABS, BV, NKK, PRS, MRS, etc
Function
High-precision pressure measurement: Provides a 4-20mA output signal and seamlessly integrates with the ship's control system.
Suitable for dynamic and static pressure monitoring, it features high precision and strong long-term stability.
Environmental adaptability: Compact design, suitable for ship equipment with limited space.
High vibration resistance and impact resistance, suitable for harsh working conditions in Marine environments.
Durability and reliability: Fully welded stainless steel design, corrosion-resistant, suitable for seawater and salt spray environments.
High EMC/EMI protection ensures stable operation in a strong electromagnetic interference environment.
Flexibility: Supports multiple pressure and electrical connection methods, facilitating integration into existing systems.
It offers an Absolute pressure version, suitable for specific Marine applications.
Application scenarios
Ship power system: Monitor the pressure in ship engines, turbines, compressors and other equipment to ensure the stable operation of the system.
Suitable for pressure measurement in fuel, lubricating oil and cooling water systems.
Marine hydraulic system: It is used for pressure monitoring and control of Marine hydraulic equipment (such as steering gears and lifting equipment).
Provide reliable pressure data to optimize equipment performance and safety.
Ship water treatment system: Monitor the pressure in the desalination system, cooling water system or ballast water system.
Corrosion-resistant materials ensure long-term reliable operation in seawater environments.
Marine engineering: Pressure monitoring applied in offshore platforms, drilling equipment or other Marine engineering equipment.
It complies with strict ship certification standards and is suitable for both offshore and nearshore applications.
Other industrial applications: Although mainly targeted at Marine applications, its high reliability and compact design are also suitable for other industrial scenarios, such as air compressors, water pumps or refrigeration systems.
