Product parameters

Pressure range: 0-400 bar (Gauge Relative)

Output signal: 4-20mA (Standard analog output, suitable for industrial control systems)

Supply voltage: 9-34 V DC

Accuracy: ±0.5% FS (full scale, typical value), maximum ±1.0% FS

Pressure connection: G1/4A ISO 228/1 (Standard pressure interface)

Electrical connection: DIN 43650-A, PG9 plug (Angle connector)

Protection grade: IP65, suitable for harsh environments

Medium temperature range: -40°C to +85°C

Ambient temperature range: -40°C to +85°C

Material: Acidic stainless steel (AISI 316L), fully welded design, corrosion-resistant

Shock and vibration resistance: Excellent shock and vibration resistance, meeting industrial requirements

Response time: Up to 4 ms (suitable for media with viscosity up to 100 cSt)

EMC/EMI protection: High electromagnetic compatibility, meeting strict industrial standards

Overload pressure: Maximum 1200 bar

Pulse suppressor: None

Function

High-precision pressure measurement: It provides a 4-20mA output signal and seamlessly integrates with control systems such as PLC and SCADA.

Suitable for dynamic and static pressure monitoring, it features high precision and strong long-term stability.

Environmental adaptability: Compact design, suitable for installation environments with limited space.

High vibration resistance and impact resistance, suitable for harsh working conditions in industrial environments.

Durability and reliability: Fully welded stainless steel design, corrosion-resistant, suitable for various media (such as air, water, oil).

High EMC/EMI protection ensures stable operation in a strong electromagnetic interference environment.

Flexibility: Supports multiple pressure and electrical connection methods, facilitating integration into existing systems.

It offers Gauge or Absolute pressure versions, suitable for a variety of measurement requirements.

Application scenarios

Pumps and compressors: Monitor the pressure of water pumps, air compressors or hydraulic pumps to ensure the system operates efficiently.

Suitable for water treatment, HVAC systems and industrial compressors.

Industrial automation: Integrated into automated production lines for monitoring pressure changes during the process, such as fluid control systems.

It is applicable to pressure measurement of non-corrosive media such as air, water and oil.

Hydraulic and pneumatic systems: Used for pressure monitoring in hydraulic and pneumatic equipment, such as injection molding machines, pneumatic tools, etc.

Provide reliable pressure data to optimize equipment performance and safety.

Water treatment system: Monitor the pressure in water treatment equipment, such as filtration systems, reverse osmosis systems or pumping stations.

Corrosion-resistant materials ensure long-term reliable operation in humid environments.

Energy management: Pressure monitoring applied in energy systems, such as boilers, refrigeration systems or heat exchangers.

Improve the system's energy efficiency and operational stability.
