Product parameters
Pressure range: 0-1 bar (relative pressure, gauge pressure)
Output signal: 4-20mA (Standard analog output, suitable for industrial control systems)
Supply voltage: 10-30 V DC
Accuracy: ±0.5% FS (full scale) or higher, depending on the calibration conditions
Pressure connection: G1/2A (or other standard interfaces, depending on the configuration)
Electrical connection: DIN 43650 plug (or other optional connection methods)
Protection grade: IP65, suitable for harsh environments
Operating temperature range: -40°C to +85°C
Material: Acidic stainless steel (AISI 316L) or similar corrosion-resistant materials, suitable for Marine environments
Shock and vibration resistance: Excellent shock and vibration resistance, meeting the requirements of Marine applications
Ship certification: Certified by LR, DNV, GL, RINA, ABS, BV, NKK, PRS, MRS, etc
Protective features: Built-in pulse snubber, capable of handling liquid hammer, cavitation and pressure peaks
Measurement type: Gauge pressure (Gauge) or Absolute pressure (Absolute), specifically the gauge pressure version
Function
High-precision pressure measurement: Provides a 4-20mA output signal and seamlessly integrates with the ship's control system.
Ensure precise measurement can be achieved under both dynamic and static pressure conditions.
Environmental adaptability: The design features high vibration resistance and impact resistance, making it suitable for extreme conditions in ships and Marine environments.
It is equipped with an internal pulse suppressor to effectively prevent the influence of liquid hammer and pressure peaks on the equipment.
Durability and reliability: Made of acidic stainless steel, it is corrosion-resistant and suitable for seawater and salt spray environments.
High EMC/EMI protection ensures stable operation in a strong electromagnetic interference environment.
Easy to install and integrate: Compact design, suitable for ship equipment with limited space.
Supports multiple pressure and electrical connection methods, facilitating connection with existing systems.
Application scenarios
Ship power system: Monitor the pressure in ship engines, turbines, compressors and other equipment to ensure the stable operation of the system.
Suitable for pressure measurement in fuel, lubricating oil and cooling water systems.
Marine hydraulic system: It is used for pressure monitoring and control of Marine hydraulic equipment (such as steering gears and lifting equipment).
Its anti-liquid hammer property makes it suitable for dynamic pressure changes in hydraulic systems.
Ship water treatment system: Monitor the pressure in the desalination system, cooling water system or ballast water system.
Corrosion-resistant materials ensure long-term reliable operation in seawater environments.
Marine engineering: Pressure monitoring applied in offshore platforms, drilling equipment or other Marine engineering equipment.
It complies with strict ship certification standards and is suitable for both offshore and nearshore applications.
Other industrial applications: Although mainly targeted at Marine applications, its high reliability and compact design are also suitable for other industrial scenarios, such as air compressors, water pumps or refrigeration systems.
