Product parameters
Pressure range: 0 to 250 bar (0 to 3625.94 psi)
Pressure reference: Gauge Relative
Output signal: 4-20 mA
Supply voltage: 10-30 VDC
Electrical connection: DIN 43650-A, Pg 11, Angular Connector
Pressure connection: G1/4 (EN 837 standard)
Accuracy: ±0.5% FS (typical value, depending on temperature range)
Response time: <4 ms (typical value)
Medium temperature range: -40 to 85°C
Ambient temperature range: -40 to 85°C
Protection grade: IP65 (depending on configuration)
Overpressure capacity: Twice the rated pressure
Material: Stainless steel casing (AISI 316L), corrosion-resistant
Certification: Complies with industrial standards such as CE and UL
Function
High-precision pressure measurement: 4-20mA output, providing high-precision gauge pressure measurement, suitable for the high-pressure range of 0-250 bar.
Integrated pulse suppressor: Effectively resists liquid hammering, cavitation and pressure peaks, ensuring reliable measurement, and is particularly suitable for hydraulic systems.
Outstanding vibration resistance: The design features excellent vibration stability and is suitable for industrial environments with significant mechanical vibrations.
High EMC/EMI protection: Built-in high electromagnetic compatibility protection, meeting strict industrial electromagnetic interference requirements.
Strong corrosion resistance: Stainless steel (AISI 316L) casing, corrosion-resistant, suitable for various media (such as hydraulic oil, water, etc.).
Wide temperature adaptability: It can operate stably in media and ambient temperatures ranging from -40 °C to 85°C, making it suitable for harsh environments.
Flexible connectivity: Standard G1/4 pressure connection and DIN 43650-A electrical connection, facilitating integration into multiple systems.
High robustness: Fully welded design, providing high burst pressure and overpressure capability, suitable for harsh environments.
Application scenarios
Hydraulic system: Monitor high-pressure hydraulic oil (0-250 bar) in equipment such as injection molding machines, presses, and hydraulic pumps.
It is suitable for demanding hydraulic applications where there is liquid hammering, cavitation or pressure peaks.
Industrial automation: Monitoring the pressure of high-pressure pneumatic or hydraulic systems in factory automation equipment.
It is used in the hydraulic control systems of heavy machinery, such as excavators, cranes, etc.
Energy industry: Monitor the pressure of hydraulic systems in wind power generation and oil and gas equipment to ensure the safe operation of the equipment.
Pressure management suitable for high-pressure cooling systems or lubrication systems.
Mechanical manufacturing: In CNC machine tools, stamping machines and other equipment, monitor the pressure of the hydraulic circuit to optimize processing accuracy.
Agricultural and construction machinery: Hydraulic systems used in agricultural machinery (such as tractors) or construction equipment (such as excavators) to handle complex working conditions.
Marine and mobile hydraulics: Although not specifically designed for Marine use, they can be applied in certain Marine hydraulic systems with non-corrosive media.
